Integrated Slip-on Module Top-Mount

$5,200.00

This versatile Slip-on module has been designed with an integrated lockable cargo compartment, and will fit most full-size pickups.

The base model features a baffled 120-gallon polypropylene tank, Honda powered centrifugal pump, drafting capabilities, and standard heavy duty Hose reel, with 100 feet 3/4 “ hose.

Choose from the options available to customize your product. For any questions about the available options please contact us.

For shipping/delivery and payment options, contact us.

Please contact us before placing your order.

Choose Your Options

Specifications

Tank/Compartment

Make/model: Wildland Products 100% polypropylene construction, with integrated cargo compartment. The tank features a structural baffling system, integrated sight glass for water level and tie down machined slots around the edges.

Capacity: 120 U.S. gallons. (200 and 300 gallon optional)

Fill port: Integral breather, strainer, fill cap.  Additional 1” NPSH fill

Drain port: 1.5” expansion plug

Cargo compartment: one 11 cubic foot compartment, with polypropylene door. Stainless steel 3 point, keyed, T-handle latch system, stainless-steel heavy-duty hinges, and 2 gas struts.

Cargo Racks: 5.5 square foot over compartment area.

Pump

Make/model: Koshin SEH-40, self-priming single stage centrifugal pump.

Suction: 1.5” MNPT

Discharge: 1.5” MNPT

Max discharge: 73 GPM

Max pressure: 61 PSI

Engine

Make /model: Honda GX50H 4 stroke, gasoline engine.

Starting system: Pull start, recoil

Max power: 1HP @ 7000 RPM.

Hose Reel

Make/model: Reel Craft series 30000. Heavy duty.

Hose capacity: 100 feet heavy duty semi rigid hose. ¾ GHT.

Rewind: Manual

Drum brake: manual, drag.

Tank Dimensions

120 gal 47 x 47 x 25 inches

200 gal 66 x 47 x 25 inches

300 gal 86 x 47 x 25 inches
